Characteristic |
Value |
| Type | MTZ |
| Weight | |
| 01. Model number (on compressor nameplate) | MTZ64HM4BVE |
| 02. Suction connection | 1-3/4" Rotolock |
| 03. Discharge connection | 1-1/4" Rotolock |
| 04. Suction connection with supplied sleeve | 7/8" ODF |
| 05. Discharge connection with supplied sleeve | 3/4" ODF |
| 06. Oil sight glass | Threaded |
| 07. Oil equalisation connection | 3/8'' flare SAE |
| 08. Oil drain connection | None |
| 09. LP gauge port | Schrader |
| 10. Internal pressure relief valve | 30 bar / 8 bar |
| 11. Cylinders | - |
| 12. Swept volume | 107.7 cm3/rev |
| 13. Displacement at 50 Hz | 18.7 m3/h |
| 14. Displacement at 60 Hz | 22.6 m3/h |
| 15. Nominal speed at 50 Hz | 2900 rpm |
| 16. Nominal speed at 60 Hz | 3600 rpm |
| 17. Nominal voltage at 50 Hz | 380-400V/3/50Hz |
| 18. Nominal voltage at 60 Hz | 460V/3/60Hz |
| 19. Voltage range at 50 Hz | 340-440 V |
| 20. Voltage range at 60 Hz | 414-506 V |
| 21. Winding resistance (between phases) | 2.41 Ohm |
| 22. Winding resistance (between phases 1-2) | 2.41 Ohm |
| 23. Winding resistance (between phases 1-3) | 2.41 Ohm |
| 24. Winding resistance (between phases 2-3) | 2.41 Ohm |
| 25. Main winding resistance | - |
| 26. Start winding resistance | - |
| 27. Maximum Continuous Current (MCC) | 15 A |
| 28. Maximum Must Trip current (MMT) | - |
| 29. Locked Rotor Current (LRA) | 67 A |
| 30. Motor protection | Internal overload protector |
| 31. Net weight | 37 kg |
| 32. Oil charge | 2 litre |
| 33. Oil type | POE - 160PZ |
| 34. Approved refrigerants | R404A, R507A, R134a, R407C |
| 35. Refrigerant charge limit | 5 kg |
| 36. Approvals (CE) | CE certified |
| 37. Approvals (UL) | UL certified (file SA6873) |
| 38. Approvals (CCC) | - |
| 39. Maximum system test pressure LP side | 25 bar(g) |
| 40. Maximum system test pressure HP side | 30 bar(g) |
| 41. Maximum differential test pressure | 30 bar |
| 42. Maximum number of starts per hour | 12 |
| 43. Packaging | Singlepack |
| 44. Pack quantity | 1 |
| 45. Parts shipped with compressor | Suction & Discharge solder sleeves, rotolock nuts and gaskets |
| 46. Parts shipped with compressor | Mounting kit with grommets, bolts, nuts, sleeves and washers |
